Alloy 20 (UNS N08020) Austenitic Seamless Pipe / Welded Pipe SCH10S SCH40S in Random 6m Length

Name: Alloy 20 UNS N08020 Austenitic Seamless Pipe Welded Pipe SCH10S SCH40S in Random 6m Length
Brand: DELTA
Price: 4000 USD

Wholesale Alloy 20 (UNS N08020) Austenitic Seamless Pipe / Welded Pipe SCH10S SCH40S in Random 6m Length from china suppliers

Brand Name : DELTA

Model Number : Alloy 20 (UNS N08020)

Certification : ISO

Place of Origin : China

MOQ : 500 kgs

Price : 4000-5150 USD/Ton

Payment Terms : T/T, Western Union, L/C

Supply Ability : 10 Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : standard packing for export

Products : N08020 Stainless Steel Pipe

Grade : Alloy 20 (UNS N08020)

Standard : ASTM GB EN

Length : 6m or custom cutting any length as request

Diameter : DN10 - DN400

Wall thickness : SCH10 - XXS or unstandard size

Type : seamless pipe

Service : cutting, polishing

application : Heat exchanger

Packing : wooden box or PP bag

Contact Now

Alloy 20 (UNS N08020) Austenitic Seamless Pipe / Welded Pipe SCH10S SCH40S in Random 6m Length

Products Name	Alloy 20 Stainless Steel Pipe
Pipe Type	Seamless Pipe . Welded Pipe
Surface	Pickling , polishing
Out Diameter	6 - 508mm
Wall Thickness	1.0 - 50.0mm
Length	6m or cutting any length as request
Standard	ASTM / GB / EN / DIN / JIS / BS / BIS
Mainly Grade	304 304L 304H 309S 310S 316L 316Ti 317L 321 347 2205 2507 904L 254SMO 800/800H Alloy20 ,Hastelloy Alloy, Monel Alloy,Inconel Alloy
Service	Cutting, Polishing, Hairline Finishing
MOQ	200 Kgs
Packing	standard packing for export
Application	Industrial , food , medical, househould

Alloy 20 (UNS N08020) is an austenitic, nickel-iron-chromium based super alloy with additions of Copper and Molybdenum which provide resistance to hostile environments, pitting, and crevice corrosion. It is also stabilized with Columbium to minimize carbide precipitation during welding. Alloy 20 appears to fall between both the stainless and nickel categories as it contains characteristics of both. It was designed for maximum resistance to acid attack and demonstrates superior resistance to stress-corrosion cracking in boiling 20% to 40% sulfuric acid, and also has excellent general corrosion resistance to sulfuric acid and to chloride stress corrosion cracking. Alloy 20 has good mechanical properties at both ambient and elevated temperatures, up to approximately

Grade Specification

ASTM/ASME: UNS N08020
EURONORM: FeMi35Cr20Cu4Mo2
DIN: 2.4660

Chemical Properties:

TYPE	C	Cr	Cu	Fe	Mn	Mo	Ni	P	Si	S	Nb (Cb)
Alloy 20 UNS N08020	0.07 max	min: 19.00 max: 21.00	min: 3.00 max: 4.00	Balance	2.00 max	min: 2.00 max: 3.00	min: 32.00 max: 38.00	0.045 max	1.00 max	0.035 max	8 XC min 1.00 max

Mechanical Properties:

Stabilized-Annealed Condition
Product Form	Tensile Strength, ksi (min)	Yield Strength, 0.2% offset ksi (min)	Elongation % (min)	Reduction of Area % (min)	Hardness Brinell (max)	Hardness Rockwell B (max)
Plate, Sheet	80	35	30	—	217	95
Bar	80	35	30	50	—	—

APPLICATIONS:

Alloy 20 was originally designed for use in sulfuric acid related applications; however, it is now frequently used in a wide variety of industries. Applications that commonly use Alloy 20 include:

Chemical and allied industries
Food and dye production
Heat exchangers
Explosives
Tanks
Valves
Pickling racks
Manufacture of synthetic rubber and plastics
Pharmaceuticals
SO2 scrubbers and other severe environments

Alloy 20 (UNS N08020) Austenitic Seamless Pipe / Welded Pipe SCH10S SCH40S in Random 6m Length
